SQL performance optimization in IBM i: Using Index Advisor and Visual Explain

In enterprise environments that rely on IBM i as their operational backbone, the efficiency of SQL queries is critical. A poorly executed query can impact response times, locks, and ultimately the user experience and overall system performance.

In this article we explore two powerful tools for improving SQL performance in IBM i: Index Advisor and Visual Explain.

Why is it important to optimize SQL queries in IBM i?

Although DB2 for i is highly efficient, it is not free from performance problems when queries:

• Do not use appropriate indexes.
• Generate unnecessary full table scans.
• Have poorly structured filters or poorly designed joins.

The good news: IBM i has advanced monitoring and optimization-suggestion tools, with no need for additional software.

What is the Index Advisor?

The Index Advisor is a DB2 for i feature that suggests indexes that would improve the performance of recently executed queries.

Where to find it: You can access it from IBM Navigator for i, within the database schema, or by using the system table:

SELECT * FROM QSYS2.SYSIXADV
WHERE TABLE_SCHEMA = 'MI_BASE_DE_DATOS';

You can also filter by a specific table:

SELECT * FROM QSYS2.SYSIXADV
WHERE TABLE_SCHEMA = 'MI_BASE_DE_DATOS' AND
      SYSTEM_TABLE_NAME = 'NOMBRE_TABLA';

What it shows:

• Tables that require new indexes.
• Recommended columns.
• Number of times the index was suggested.
• Associated example query.

Advantages:

• Suggestions based on real usage.
• Generates the suggested index DDL directly.
• Updates dynamically as queries are executed.

How to interpret the Index Advisor suggestions?

The Index Advisor in IBM i monitors executed queries and detects table-access patterns where an index would have reduced response time, based on the analysis of the execution plans generated by the DB2 for i optimizer.

How to query the suggestions?

SELECT TABLE_NAME, LEADING_COLUMN_KEYS, TIMES_ADVISED, INDEX_TYPE,
       SYSTEM_TABLE_SCHEMA, LAST_ADVISED
FROM QSYS2.SYSIXADV
ORDER BY TIMES_ADVISED;

Key columns:

• TABLE_NAME: table where creating the index is suggested.
• LEADING_COLUMN_KEYS: recommended columns.
• TIMES_ADVISED: how many times it was suggested (higher = more relevant).
• INDEX_TYPE: type of index.
• LAST_ADVISED: last time the suggestion was triggered.

When should you create the index?

• If it is suggested frequently (>10 times).
• If the columns are in WHERE or JOIN clauses.
• If a similar index does not exist.
• If the table has a medium or high data volume.
• If you confirm that the query is not using efficient indexes (Plan Cache).

When should you NOT create it?

• If the table has few records.
• If the column has low selectivity (repeated values).
• If a suitable composite index already exists.
• If there are many indexes and you may affect write performance.

Best practices

1. Review the associated query (from Visual Explain).
2. Test the index in a test environment.
3. Use semantic names:

   CREATE INDEX CLIENTE_IDX_ESTADO_FECHA
   ON CLIENTE (ESTADO, FECHA_REGISTRO);


4. Monitor after applying the index using Visual Explain.

Practical example

Frequent query:

SELECT * FROM FACTURAS
WHERE FECHA BETWEEN '2023-01-01' AND '2023-12-31'
AND ESTADO = 'PENDIENTE';

Recommended index:

CREATE INDEX FACTURAS_IDX1
ON FACTURAS (FECHA, ESTADO);

Using Visual Explain in IBM i Access Client Solutions

Visual Explain is a graphical tool included in IBM i Access Client Solutions that lets you visualize in detail how DB2 executes an SQL query.

What is it for?

• It analyzes SQL execution plans graphically.
• It shows whether indexes are being used or not.
• It lets you identify costly operations such as table scans or nested loop joins.
• It makes it easier to identify bottlenecks in complex queries.

How do you access it?

1. Open IBM i Access Client Solutions.
2. Go to the SQL Performance Center module.
3. Paste your SQL query and run it with Visual Explain.
4. Examine the generated diagram to see each step of the execution plan.

What should you look at?

• Red or yellow icons indicate costly operations.
• Review index usage: if a table scan appears you may need one.
• Check the estimated and actual times of each operation.
• You can click on each node of the graph to see more details.

Benefits over textual analysis

• It is more intuitive than reviewing only the PLAN_CACHE_EVENT.
• It helps explain the problem to non-technical teams.
• Useful for validating improvements after applying indexes or refactoring queries.

Practical case: Identifying slow queries and applying Index Advisor

Scenario:
A billing query takes 7 seconds to respond. When reviewing it with Visual Explain, we see that it does a table scan of a table with 5 million records.

Step 1: Use Visual Explain to view the problematic query

1. Open IBM i Access Client Solutions.
2. Go to the SQL Performance Center module.
3. Paste your SQL query and run it with Visual Explain.
4. Examine the generated diagram to see each step of the execution plan.

Step 2: Review the Index Advisor suggestions

SELECT TABLE_NAME, LEADING_COLUMN_KEYS, TIMES_ADVISED
FROM QSYS2.SYSIXADV
WHERE TABLE_NAME = 'FACTURAS';

Step 3: Create the suggested index

CREATE INDEX FACTURAS_IDX1
ON FACTURAS (FECHA_FACTURA, ESTADO);

Result:
The same query now runs in less than 500 ms, thanks to the correctly suggested index.

Best practices to maintain performance

• Run periodic cleanups of the Index Advisor:

CALL QSYS2.CLEAR_INDEX_ADVISOR();

• Evaluate indexes with low usage.
• Automate Plan Cache snapshots weekly.
• Use Visual Explain in IBM i Access Client Solutions for graphical analysis.

Conclusion

IBM i provides you with advanced tools such as Index Advisor and Plan Cache Snapshots that let you detect, analyze, and fix SQL performance problems in real time, based on the actual usage of the system.

You don’t need expensive external tools or migrations to other platforms. With technical knowledge and best practices, you can keep your DB2 for i systems highly optimized, modern, and efficient.
